Valve, Control, Kimray, 2" Body, 1/2" Trim, 2000#
Valve, Control, Kimray, 2" Body, 1/2" Trim, 2000#
$637.50 (USD)
Location:Pennsylvania
Available quantity:1
orCall 1 (844) 564-4237
Description
The Stem-Guided High Pressure Control Valve is a non-balanced valve that can be used as a dump valve, pressure regulator, suction controller, recirculation valve, as well as in plunger lift or flowback applications. The Stem-Guided Control Valve has smaller trim sizes (available in 1" and 2" end connections) for smaller valve coefficients (Cv) compared to the Cage-Guided series. "Stem-guided" refers to the stem itself guiding the trim into its seat.
Specifications
| Manufacturer | Kimray |
| Model | 2", 2000# |
| Condition | New |
| Stock Number | ECNCB |
| Connection Size (in.) | 2 |
| Subcategory 2 | Control |
| Warehouse Location | PA1B3 |
| Connection Type | FNPT |
| Body Style | Through Body |
| Body Material | Steel |
| Max Working Pressure (psi) | 2000 |
| Operation | Pneumatic |
| Trim Size (in.) | .1/2 |
| Trim Type | Quick Opening |
| Trim Material | Carbide |
| Process Fluid | Liquid and Gas |
| Actuator Spring Pressure (psi) | 20 |
| Fail Position | Closed-Field Reversible |
| Origin code | OC01 |
