Fitting, Orifice, Single Chamber, Weld, 6", RF600, SCH40

The simple and efficient design allows quick change of the orifice plate by removing the clamp bar with bolts and then removing the seal bar/orifice plate carrier

assembly.

HNBR or Viton bonded to a stainless steel metal insert which retains seal shape, ensuring no protrusion into the bore. The Orifice Seal design provides a positive seal against the orifice plate and the upstream seat face, while the carrier creates a positive stop against the downstream seat face.

The seal bar is specially designed with a guide pin, making reinstallation of the carrier assembly simple and efficient, while maintaining the integrity of the eccentricity requirements.
