Thermocouple, Rosemount, 1/2"x8-1/2",

The Rosemount 214C thermocouples are designed to provide flexible and reliable temperature measurements in process monitoring and control environments. Choose from three thermocouple types to best suit your application needs:

• Type J is one of the most common thermocouples (iron & constantan conductors)
• Type K is used for high temperature applications (Chromel & Alumel conductors)
• Type T is used for low temperature applications (copper & constantan conductors)

Rosemount 214C temperature sensors are available with immersion lengths from 2 to 78-1/2 inches (50 to 2000mm) in 1/4-inch (5mm) increments. All sensor styles and lengths have a standard 1/4-inch (6mm) nominal diameter. Multiple options for connection heads, accuracy, mounting styles, extensions and other factors are also available.

The Rosemount 214C temperature sensors can be combined with process-ready or hand-tight transmitter, sensor, and/or thermowell assemblies to deliver a complete temperature solution.
