Valve, Motor, 2" 300 RF, 740# WP, Kimray
Valve, Motor, 2" 300 RF, 740# WP, Kimray
$562.50 (USD)
Location:Pennsylvania
Available quantity:1
Description
The Stem-Guided High Pressure Control Valve is a non-balanced valve that can be used as a dump valve, pressure regulator, suction controller, recirculation valve, as well as in plunger lift or flowback applications.
The Stem-Guided Control Valve has smaller trim sizes (available in 1" and 2" end connections) for smaller valve coefficients (Cv) compared to the Cage-Guided series. "Stem-guided" refers to the stem itself guiding the trim into its seat.
It can be fitted with optional electric actuation or operated with compressed air for zero-emission requirements.
The EAD provides increased flow at lower operating pressures. Maximum pressure drop is 300psig. For on-off service only. Uses a standard valve body and has a Teflon seal.
Specifications
| Manufacturer | Kimray |
| Model | 2" FMT 300 RF |
| Condition | New |
| Serial Number | 2160290354 |
| Stock Number | RD-40261312757440467 |
| Connection Size (in.) | 2 |
| Subcategory 2 | Control |
| Warehouse Location | PA2G5 |
| Connection Type | FNPT |
| Body Style | Angle body |
| Body Material | Steel |
| Max Working Pressure (psi) | 740 |
| Operation | Pneumatic |
| Trim Size (in.) | 2 |
| Process Fluid | Liquid and Gas |
| Origin code | OC01 |
